AmericAire 24,000 Btu. R410A 220 Volt Heat Pump Inverter Ductless Split System

Shipping: $79.00 Contiguous U.S

Shipping Option:
Qty: - +
   - OR -

Installation Manual
User Manual
Submittal Sheet

AmericAire 24,000 Btu. Heat Pump Split Systems come standard with an indoor unit (evaporator), outdoor unit (condenser) and a LCD remote control. Indoor and outdoor components are connected with electrical wiring and refrigerant line sets (Sold Separately). Inverter compressors run more smoothly and efficiently saving money and extending the compressor life

Model Features:

  • Multi-Fold Evaporator
  • Three Dimensional Swing Delivery
  • Sleep Mode Operation
  • Independent De-Humidification
  • On/Off Timer
  • Intelligent Defrosting
  • Extra Quiet Operation
  • Cold Catalyst Filter
Cooling/Heating Capacity Btu. 24,000
Average Cooling Capacity Feet 1,200
Power Supply Volt 220
Power Hertz 60
Efficiency SEER 16.0
Air Flow Rate CFM 725
Moisture Removal Pt/h 2.8
Noise Level dBa 44
Auto Restart YES
Breaker Size Amp 15
Heating Power Input Watt 2,315
Indoor Dimensions WxHxD in. 52.0 x 15.6 x 12.0
Net Weight Indoor Unit Lbs. 44
Outdoor Dimensions WxHxD in. 40.2 x 34.1 x 17.1
Net Weight Outdoor Unit Lbs. 121
Compressor Type Inverter
Refrigerant Type R410A
Defrosting Method AUTO
Compressor Range Watt 3,600-8,100
Piping Connection Liquid 3/8"
Suction 5/8"
Drain 1/2"
Factory R410 Charge Feet 16.5
Max Installation Distance Feet 35
Max Height Distance Feet 17
Compressor Warranty Year(s) 5
Circuit Board Warranty Year(s) 1
Parts/Labor Warranty Year(s) 1
